RSL10
Table 3. ELECTRICAL PERFORMANCE SPECIFICATIONS
Unless otherwise noted, the specifications mentioned in the table below are valid at 25°C at VBAT = VDDO = 1.25 V.
Description
Symbol
Conditions
Min
Typ
Max
Units
EEMBC CoreMark BENCHMARK for the Arm Cortex−M3 Processor and the LPDSP32 DSP
Arm Cortex−M3 processor and
LPDSP32 running from RAM,
VBAT = 1.25 V
At 48 MHz SYSCLK
At 48 MHz SYSCLK
108
Core
Mark/
mA
Arm Cortex−M3 processor and
LPDSP32 running from RAM,
VBAT = 3 V
257
Core
Mark/
mA
INTERNALLY GENERATED VDDC: Digital Block Supply Voltage
Supply voltage: operating range
VDDC
0.92
1.15
1.32
(Note 2)
V
Supply voltage: trimming range
Supply voltage: trimming step
VDDC
0.75
1.38
V
RANGE
VDDC
−
10
−
mV
STEP
INTERNALLY GENERATED VDDM: Memories Supply Voltage
Supply voltage: operating range
VDDM
1.05
1.15
1.32
(Note 3)
V
Supply voltage: trimming range
Supply voltage: trimming step
VDDM
0.75
1.38
V
RANGE
VDDM
−
10
−
mV
STEP
INTERNALLY GENERATED VDDRF: Radio Front end supply voltage
Supply voltage: operating range
VDDRF
1.00
1.10
1.32 (Notes
4 and 5)
V
Supply voltage: trimming range
Supply voltage: trimming step
VDDRF
0.75
1.38
V
RANGE
VDDRF
−
10
−
mV
STEP
INTERNALLY GENERATED VDDPA: Optional Radio Power Amplifier Supply Voltage
Supply voltage: operating range
Supply voltage: trimming range
Supply voltage: trimming step
Supply voltage: trimming step
VDDPA
VDDPA
1.05
1.05
−
1.3
1.68
1.68
−
V
V
RANGE
VDDPA
10
10
mV
mV
STEP
STEP
DCDC
−
−
VDDO PAD SUPPLY VOLTAGE: Digital Level High Voltage
Digital I/O supply VDDO
INDUCTIVE BUCK DC−DC CONVERTER
1.1
1.25
3.3
V
VBAT range when the DC−DC
DCDC
IN_RANGE
1.4
1.1
1.1
−
3.3
3.3
1.32
−
V
V
converter is active (Note 6)
VBAT range when the LDO is
active
LDO
IN_RANGE
Output voltage: trimming range
DCDC
OUT_RANGE
1.2
10
V
Supply voltage: trimming step
POWER−ON RESET
POR voltage
DCDC
mV
STEP
POR
VBAT
0.4
0.8
1.0
V
RADIO FRONT−END: General Specifications
RF input impedance
Input reflection coefficient
Data rate FSK / MSK / GFSK
Data rate 4−FSK
Z
Single ended
All channels
−
−
50
−
−
W
in
S
11
−8
dB
R
OQPSK as MSK
62.5
−
1000
−
3000
4000
2000
kbps
kbps
kbps
FSK
On−air data rate
bps
GFSK
250
RADIO FRONT−END: Crystal and Clock Specifications
Xtal frequency Fundamental
F
XTAL
48
MHz
