Functional Description (Continued)
10099533
FIGURE 12. NAND Tree Test Structure
12.0 FAN MANUFACTURERS
Mechatronics Inc.
P.O. Box 20
Manufacturers of cooling fans with tachometer outputs are
listed below:
Mercer Island, WA 98040
800 453-4569
NMB Tech
9730 Independence Ave.
Chatsworth, California 91311
818 341-3355
Various sizes available with tach output option.
Sanyo Denki America, Inc.
468 Amapola Ave.
818 341-8207
Torrance, CA 90501
310 783-5400
Model
Number
2408NL
Frame Size
Airflow CFM
9-16
Model Number
109P06XXY601
109R06XXY401
109P08XXY601
109R08XXY401
Frame Size
Airflow
CFM
2.36 in sq. X 0.79 in
(60 mm sq. X 20 mm)
2.36 in sq. X 0.98 in
(60 mm sq. X 25 mm)
3.15 in sq. X 0.79 in
(80 mm sq. X 20 mm)
3.15 in sq. X 0.98 in
(80 mm sq. X 25 mm)
2.36 in sq. X 0.79 in
(60 mm sq. X 20 mm)
2.36 in sq. X 0.98 in
(60 mm sq. X 25 mm)
3.15 in sq. X 0.79 in
(80 mm sq. X 20 mm)
3.15 in sq. X 0.98 in
(80 mm sq. X 25 mm)
11-15
2410ML
3108NL
3110KL
14-25
13-28
23-30
21-42
25-42
25-40
23
