Mitsubishi microcomputers
M16C / 61 Group
SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER
Bus Control
(5) The _R__D___Y__ signal
________
RDY is a signal that facilitates access to an external device that requires long access time. As shown in
________
Figure 1.11.3, if an “L” is being input to the RDY at the BCLK falling edge, the bus turns to the wait state.
________
If an “H” is being input to the RDY pin at the BCLK falling edge, the bus cancels the wait state. Table
1.11.4 shows the state of the microcomputer with the bus in the wait state, and Figure 1.11.3 shows an
____
________
example in which the RD signal is prolonged by the RDY signal.
________
The RDY signal is valid when accessing the external area during the bus cycle in which bits 4 to 7 of the
________
chip select control register (address 000816) are set to “0”. The RDY signal is invalid when setting “1” to all
________
bits 4 to 7 of the chip select control register (address 000816), but the RDY pin should be treated as
properly as in non-using.
Table 1.11.4. Microcomputer status in ready state (Note)
Item
Status
Oscillation
On
___
_____
________
R/W signal, address bus, data bus, CS
Maintain status when RDY signal received
__________
ALE signal, HLDA, programmable I/O ports
Internal peripheral circuits
On
________
Note: The RDY signal cannot be received immediately prior to a software wait.
In an instance of separate bus
BCLK
RD
CS
i
(i=0 to 3)
RDY
tsu(RDY - BCLK)
Accept timing of RDY signal
In an instance of multiplexed bus
BCLK
RD
CS
i
(i=0 to 3)
RDY
tsu(RDY - BCLK)
Accept timing of RDY signal
: Wait using RDY signal
: Wait using software
_____
________
Figure 1.11.3. Example of RD signal extended by RDY signal
26
