MT9079
Bit
Name
Functional Description
Errored FAS Counter. An 8 bit
counter that is incremented once for
every receive frame alignment signal
that contains one or more errors.
Bit
Name
Functional Description
7 - 0
EFAS7
-
EFAS0
7 - 0
EC7
-
EC0
E-bit Error Counter Bits Seven to
Zero. These are the least significant
eight bits of the E-bit error counter.
Table 62 - Errored Frame Alignment Signal Counter
(Page 4, Address 1AH)
Table 65 - E-bit Error Counter EBt
(Page 4, Address 1EH)
Bit
Name
Functional Description
Bit
Name
Functional Description
7 - 0
BPV15
-
Most Significant Bits of the BPV
Counter. The most significant eight
bits of a 16 bit counter that is incre-
mented once for every bipolar viola-
tion error received.
7 - 0
CC7
-
CC0
CRC-4 Error Counter Bits Seven to
Zero. These are the least significant
eight bits of the CRC-4 error counter.
BPV8
Table 66 - CRC-4 Error Counter CEt
(Page 4, Address 1FH)
Table 63 - Most Significant Bits of the BPV Counter
(Page 4,Address 1CH)
Bit
Name
Functional Description
7 - 0
BPV7
-
BPV0
Least Significant Bits of the BPV
Counter. The least significant eight
bits of a 16 bit counter that is incre-
mented once for every bipolar viola-
tion error received.
Table 64 - Least Significant Bits of the BPV
Counter (Page 4, Address 1DH)
