MT9076
Preliminary Information
20.0 Control and Status Registers
20.1
T1 Mode
20.1.1 Master Control 1 (Page 01H) (T1)
Address
Register
Function
(A4A3A2A1A0)
10H (Table 21)
11H (Table 22)
12H (Table 23)
Framing Mode Select
ESF, SCL96, CXC, RS1-0, FSI, ReFR,
MFReFR
Transmit Alarm Control Word
Data Link Control Word
ESFYEL, TXSECY, D4YEL, TxAO, LUA, LDA,
D4SECY, SO
EDL, BIOMEn, EXZ, TxPDVS, TxSYNC, TRSP,
JTS, H1R64
13H (Table 24)
14H (Table 25)
Transmit Bit Oriented Message
signaling Control Word
BIOMTx7-0
DSToEn, CSToEn, RBEn, DBEn, MSN, SM1-0,
JYEL
15H (Table 26)
Coding and Loopback Control Word
RxB8ZS, MLBK,TxB8ZS,FBS, DLBK, RLBK,
SLBK, PLBK
16H (Table 27)
17H (Table 28)
18H (Table 29)
19H (Table 30)
Reserved
Set all bits to zero for normal operation
Transmit Elastic buffer Set Delay Word
Transmit Message Word
Error Insertion Word
TxTSD7-0
TXM7-0
BPVE, CRCE, FTE, FSE, LOSE, PERR, L32Z,
LOS/LOF
1AH (Table 31)
1BH (Table 32)
1CH (Table 33)
1DH (Table 34)
1EH (Table 35)
1FH (Table 36)
Reset Control Word
RST, SPND, INTA, CNTCLR, SAMPLE, OOFP,
D20
Interrupt Mask Word Zero
Interrupt Mask Word One
Interrupt Mask Word Two
Interrupt Mask Word Three
LIU Receiver Word
TFSYNIM, MFSYNIM, BIOMTIM, AISIM,
LOSIM, SEFIM, TxSLPIM, RxSLPIM
FEIM, CRCIM, YELIM, LCVIM, COFAIM,
PRBSIM, PDVIM
FEOM, CRCOM, OOFOM, COFAOM, LCVOM,
PRBSOM, PRBSMFOM,MFOOFOM
HDLC0IM,HDLC1IM,HDLC2IM,LCDIM,
1SECIM, 5SECIM, BIOIM, SIGIM
NRZ, Res, RxA1-0, RxEQ2-0
Table 20 - Master Control 1 (Page 1) (T1)
58
