PIC24FJ64GA104 FAMILY
3.3.2
DIVIDER
3.3.3
MULTI-BIT SHIFT SUPPORT
The divide block supports signed and unsigned integer
divide operations with the following data sizes:
The PIC24F ALU supports both single bit and
single-cycle, multi-bit arithmetic and logic shifts.
Multi-bit shifts are implemented using a shifter block,
capable of performing up to a 15-bit arithmetic right
shift, or up to a 15-bit left shift, in a single cycle. All
multi-bit shift instructions only support Register Direct
Addressing for both the operand source and result
destination.
1. 32-bit signed/16-bit signed divide
2. 32-bit unsigned/16-bit unsigned divide
3. 16-bit signed/16-bit signed divide
4. 16-bit unsigned/16-bit unsigned divide
The quotient for all divide instructions ends up in W0
and the remainder in W1. Sixteen-bit signed and
unsigned DIV instructions can specify any W register
for both the 16-bit divisor (Wn), and any W register
(aligned) pair (W(m + 1):Wm) for the 32-bit dividend.
The divide algorithm takes one cycle per bit of divisor,
so both 32-bit/16-bit and 16-bit/16-bit instructions take
the same number of cycles to execute.
A full summary of instructions that use the shift
operation is provided below in Table 3-2.
TABLE 3-2:
Instruction
INSTRUCTIONS THAT USE THE SINGLE AND MULTI-BIT SHIFT OPERATION
Description
ASR
SL
Arithmetic shift right source register by one or more bits.
Shift left source register by one or more bits.
LSR
Logical shift right source register by one or more bits.
DS39951C-page 30
2010 Microchip Technology Inc.
