PIC24FJ64GA104 FAMILY
REGISTER 10-25: RPOR10: PERIPHERAL PIN SELECT OUTPUT REGISTER 10(1)
U-0
—
U-0
—
U-0
—
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
RP21R4
RP21R3
RP21R2
RP21R1
RP21R0
bit 15
bit 8
U-0
—
U-0
—
U-0
—
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
RP20R4
RP20R3
RP20R2
RP20R1
RP20R0
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 15-13
bit 12-8
Unimplemented: Read as ‘0’
RP21R<4:0>: RP21 Output Pin Mapping bits
Peripheral output number n is assigned to pin, RP21 (see Table 10-3 for peripheral function numbers).
Unimplemented: Read as ‘0’
bit 7-5
bit 4-0
RP20R<4:0>: RP20 Output Pin Mapping bits
Peripheral output number n is assigned to pin, RP20 (see Table 10-3 for peripheral function numbers).
Note 1: This register is unimplemented in 28-pin devices; all bits read as ‘0’.
REGISTER 10-26: RPOR11: PERIPHERAL PIN SELECT OUTPUT REGISTER 11(1)
U-0
—
U-0
—
U-0
—
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
RP23R4
RP23R3
RP23R2
RP23R1
RP23R0
bit 15
bit 8
U-0
—
U-0
—
U-0
—
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
RP22R4
RP22R3
RP22R2
RP22R1
RP22R0
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 15-13
bit 12-8
Unimplemented: Read as ‘0’
RP23R<4:0>: RP23 Output Pin Mapping bits
Peripheral output number n is assigned to pin, RP23 (see Table 10-3 for peripheral function numbers).
Unimplemented: Read as ‘0’
bit 7-5
bit 4-0
RP22R<4:0>: RP22 Output Pin Mapping bits
Peripheral output number n is assigned to pin, RP22 (see Table 10-3 for peripheral function numbers).
Note 1: This register is unimplemented in 28-pin devices; all bits read as ‘0’.
