PIC24FJ64GA104 FAMILY
REGISTER 10-23: RPOR8: PERIPHERAL PIN SELECT OUTPUT REGISTER 8(1)
U-0
—
U-0
—
U-0
—
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
RP17R4
RP17R3
RP17R2
RP17R1
RP17R0
bit 15
bit 8
U-0
—
U-0
—
U-0
—
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
RP16R4
RP16R3
RP16R2
RP16R1
RP16R0
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 15-13
bit 12-8
Unimplemented: Read as ‘0’
RP17R<4:0>: RP17 Output Pin Mapping bits
Peripheral output number n is assigned to pin, RP17 (see Table 10-3 for peripheral function numbers).
Unimplemented: Read as ‘0’
bit 7-5
bit 4-0
RP16R<4:0>: RP16 Output Pin Mapping bits
Peripheral output number n is assigned to pin, RP16 (see Table 10-3 for peripheral function numbers).
Note 1: This register is unimplemented in 28-pin devices; all bits read as ‘0’.
REGISTER 10-24: RPOR9: PERIPHERAL PIN SELECT OUTPUT REGISTER 9(1)
U-0
—
U-0
—
U-0
—
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
RP19R4
RP19R3
RP19R2
RP19R1
RP19R0
bit 15
bit 8
U-0
—
U-0
—
U-0
—
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
RP18R4
RP18R3
RP18R2
RP18R1
RP18R0
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 15-13
bit 12-8
Unimplemented: Read as ‘0’
RP19R<4:0>: RP19 Output Pin Mapping bits
Peripheral output number n is assigned to pin, RP19 (see Table 10-3 for peripheral function numbers).
Unimplemented: Read as ‘0’
bit 7-5
bit 4-0
RP18R<4:0>: RP18 Output Pin Mapping bits
Peripheral output number n is assigned to pin, RP18 (see Table 10-3 for peripheral function numbers).
Note 1: This register is unimplemented in 28-pin devices; all bits read as ‘0’.
