PIC24FJ64GA104 FAMILY
REGISTER 10-19: RPOR4: PERIPHERAL PIN SELECT OUTPUT REGISTER 4
U-0
—
U-0
—
U-0
—
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
RP9R4
RP9R3
RP9R2
RP9R1
RP9R0
bit 15
bit 8
U-0
—
U-0
—
U-0
—
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
RP8R4
RP8R3
RP8R2
RP8R1
RP8R0
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 15-13
bit 12-8
Unimplemented: Read as ‘0’
RP9R<4:0>: RP9 Output Pin Mapping bits
Peripheral output number n is assigned to pin, RP9 (see Table 10-3 for peripheral function numbers).
Unimplemented: Read as ‘0’
bit 7-5
bit 4-0
RP8R<4:0>: RP8 Output Pin Mapping bits
Peripheral output number n is assigned to pin, RP8 (see Table 10-3 for peripheral function numbers).
REGISTER 10-20: RPOR5: PERIPHERAL PIN SELECT OUTPUT REGISTER 5
U-0
—
U-0
—
U-0
—
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
RP11R4
RP11R3
RP11R2
RP11R1
RP11R0
bit 15
bit 8
U-0
—
U-0
—
U-0
—
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
RP10R4
RP10R3
RP10R2
RP10R1
RP10R0
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 15-13
bit 12-8
Unimplemented: Read as ‘0’
RP11R<4:0>: RP11 Output Pin Mapping bits
Peripheral output number n is assigned to pin, RP11 (see Table 10-3 for peripheral function numbers).
Unimplemented: Read as ‘0’
bit 7-5
bit 4-0
RP10R<4:0>: RP10 Output Pin Mapping bits
Peripheral output number n is assigned to pin, RP10 (see Table 10-3 for peripheral function numbers).
DS39951C-page 138
2010 Microchip Technology Inc.
