PIC17C75X
FIGURE 15-5: SSPCON1: SYNC SERIAL PORT CONTROL REGISTER1 (ADDRESS 11h, BANK 6)
R/W-0
R/W-0
R/W-0
R/W-0
CKP
R/W-0
R/W-0
R/W-0
R/W-0
WCOL SSPOV SSPEN
bit7
SSPM3 SSPM2 SSPM1 SSPM0
bit0
R = Readable bit
W = Writable bit
U = Unimplemented bit,
read as ‘0’
- n =Value at POR reset
bit 7:
WCOL: Write Collision Detect bit
Master Mode:
2
1 = A write to the SSPBUF register was attempted while the I C conditions were not valid for a
transmission to be started
0 = No collision
Slave Mode:
1 = The SSPBUF register is written while it is still transmitting the previous word
(must be cleared in software)
0 = No collision
bit 6:
SSPOV: Receive Overflow Indicator bit
In SPI mode
1 = A new byte is received while the SSPBUF register is still holding the previous data. In case of over-
flow, the data in SSPSR is lost. Overflow can only occur in slave mode. The user must read the
SSPBUF, even if only transmitting data, to avoid setting overflow. In master mode the overflow bit is
not set since each new reception (and transmission) is initiated by writing to the SSPBUF register.
0 = No overflow
2
In I C mode
1 = A byte is received while the SSPBUF register is still holding the previous byte. SSPOV is a "don’t
care" in transmit mode. SSPOV must be cleared in software in either mode.
0 = No overflow
bit 5:
SSPEN: Synchronous Serial Port Enable bit
In SPI mode
1 = Enables serial port and configures SCK, SDO, and SDI as serial port pins
0 = Disables serial port and configures these pins as I/O port pins
2
In I C mode
1 = Enables the serial port and configures the SDA and SCL pins as serial port pins
0 = Disables serial port and configures these pins as I/O port pins
Note: In both modes, when enabled, these pins must be properly configured as input or output.
bit 4:
CKP: Clock Polarity Select bit
In SPI mode
1 = Idle state for clock is a high level
0 = Idle state for clock is a low level
2
In I C slave mode
SCK release control
1 = Enable clock
0 = Holds clock low (clock stretch) (Used to ensure data setup time)
In I2C master mode
Unused in this mode
bit 3-0: SSPM3:SSPM0: Synchronous Serial Port Mode Select bits
0000= SPI master mode, clock = FOSC/4
0001= SPI master mode, clock = FOSC/16
0010= SPI master mode, clock = FOSC/64
0011= SPI master mode, clock = TMR2 output/2
0100= SPI slave mode, clock = SCK pin. SS pin control enabled.
0101= SPI slave mode, clock = SCK pin. SS pin control disabled. SS can be used as I/O pin
2
0110= I C slave mode, 7-bit address
2
0111= I C slave mode, 10-bit address
2
1000= I C master mode, clock = FOSC / (4 * (SSPADD+1) )
1xx1= Reserved
1x1x= Reserved
