PIR1 REGISTER
The PIR1 register contains the interrupt flag bits, as
shown in Register 7-6.
Note:
Interrupt flag bits are set when an interrupt
condition occurs, regardless of the state of
its corresponding enable bit or the Global
Enable bit, GIE, of the INTCON register.
User software should ensure the
appropriate interrupt flag bits are clear prior
to enabling an interrupt.
REGISTER 7-6:
PIR1: PERIPHERAL INTERRUPT REQUEST REGISTER 1
R/W-0/0
TMR1GIF
bit 7
R/W-0/0
ADIF
R-0/0
RCIF
R-0/0
TXIF
R/W-0/0
SSPIF
R/W-0/0
CCP1IF
R/W-0/0
TMR2IF
R/W-0/0
TMR1IF
bit 0
Legend:
R = Readable bit
W = Writable bit
x = Bit is unknown
‘0’ = Bit is cleared
U = Unimplemented bit, read as ‘0’
-n/n = Value at POR and BOR/Value at all other Resets
u = Bit is unchanged
‘1’ = Bit is set
bit 7
bit 6
bit 5
bit 4
bit 3
bit 2
bit 1
bit 0
TMR1GIF: Timer1 Gate Interrupt Flag bit
1= Interrupt is pending
0= Interrupt is not pending
ADIF: A/D Converter Interrupt Flag bit
1= Interrupt is pending
0= Interrupt is not pending
RCIF: USART1 Receive Interrupt Flag bit
1= Interrupt is pending
0= Interrupt is not pending
TXIF: USART1 Transmit Interrupt Flag bit
1= Interrupt is pending
0= Interrupt is not pending
SSPIF: Synchronous Serial Port (MSSP1) Interrupt Flag bit
1= Interrupt is pending
0= Interrupt is not pending
CCP1IF: CCP1 Interrupt Flag bit
1= Interrupt is pending
0= Interrupt is not pending
TMR2IF: Timer2 to PR2 Interrupt Flag bit
1= Interrupt is pending
0= Interrupt is not pending
TMR1IF: Timer1 Overflow Interrupt Flag bit
1= Interrupt is pending
0= Interrupt is not pending
DS41414A-page 94
Preliminary
2010 Microchip Technology Inc.
