ENC28J60
2.2
Oscillator Start-up Timer
2.0
2.1
EXTERNAL CONNECTIONS
Oscillator
The ENC28J60 contains an Oscillator Start-up Timer
(OST) to ensure that the oscillator and integrated PHY
have stabilized before use. The OST does not expire
until 7500 OSC1 clock cycles (300 μs) pass after
Power-on Reset or wake-up from Power-Down mode
occurs. During the delay, all Ethernet registers and
buffer memory may still be read and written to through
the SPI bus. However, software should not attempt to
transmit any packets (set ECON1.TXRTS), enable
reception of packets (set ECON1.RXEN) or access any
MAC, MII or PHY registers during this period.
The ENC28J60 is designed to operate at 25 MHz with
a crystal connected to the OSC1 and OSC2 pins. The
ENC28J60 design requires the use of a parallel cut
crystal. Use of a series cut crystal may give a frequency
out of the crystal manufacturer specifications. A typical
oscillator circuit is shown in Figure 2-1.
The ENC28J60 may also be driven by an external clock
source connected to the OSC1 pin as shown in
Figure 2-2.
When the OST expires, the CLKRDY bit in the ESTAT
register will be set. The application software should poll
this bit as necessary to determine when normal device
operation can begin.
FIGURE 2-1:
CRYSTAL OSCILLATOR
OPERATION
ENC28J60
Note:
After a Power-on Reset, or the ENC28J60
is removed from Power-Down mode, the
CLKRDY bit must be polled before
transmitting packets, enabling packet
reception or accessing any MAC, MII or
PHY registers.
OSC1
C
1
To Internal Logic
XTAL
(2)
RF
(1)
RS
C
2
OSC2
Note 1: A series resistor, RS, may be required for AT
strip cut crystals.
2: The feedback resistor, RF, is typically in the
range of 2 to 10 MΩ.
FIGURE 2-2:
EXTERNAL CLOCK
SOURCE(1)
ENC28J60
3.3V Clock from
External System
OSC1
(2)
Open
OSC2
Note 1: Duty cycle restrictions must be observed.
2: A resistor to ground may be used to reduce
system noise. This may increase system
current.
