Chapter 1: Cyclone IV Device Datasheet
1–23
Switching Characteristics
Table 1–23 lists the Cyclone IV GX transceiver block AC specifications.
Table 1–23. Transceiver Block AC Specification for Cyclone IV GX Devices (1), (2)
C6
C7, I7
Min Typ
C8
Symbol/
Description
Conditions
Unit
Min Typ Max
Max Min Typ Max
(3)
PCIe Transmit Jitter Generation
Total jitter at 2.5 Gbps
(Gen1)
Compliance pattern
—
—
0.25
—
—
0.25
—
—
0.25
UI
UI
(3)
PCIe Receiver Jitter Tolerance
Total jitter at 2.5 Gbps
(Gen1)
Compliance pattern
> 0.6
> 0.6
> 0.6
(4)
GIGE Transmit Jitter Generation
Deterministic jitter
Pattern = CRPAT
—
—
—
—
0.14
—
—
—
—
0.14
—
—
—
—
0.14
UI
(peak-to-peak)
Total jitter (peak-to-peak) Pattern = CRPAT
0.279
0.279
0.279 UI
(4)
GIGE Receiver Jitter Tolerance
Deterministic jitter
Pattern = CJPAT
> 0.4
> 0.4
> 0.4
UI
UI
tolerance (peak-to-peak)
Combined deterministic
and random jitter
Pattern = CJPAT
> 0.66
> 0.66
> 0.66
tolerance (peak-to-peak)
Notes to Table 1–23:
(1) Dedicated refclk pins were used to drive the input reference clocks.
(2) The jitter numbers specified are valid for the stated conditions only.
(3) The jitter numbers for PIPE are compliant to the PCIe Base Specification 2.0.
(4) The jitter numbers for GIGE are compliant to the IEEE802.3-2002 Specification.
Core Performance Specifications
The following sections describe the clock tree specifications, PLLs, embedded
multiplier, memory block, and configuration specifications for Cyclone IV Devices.
Clock Tree Specifications
Table 1–24 lists the clock tree specifications for Cyclone IV devices.
Table 1–24. Clock Tree Performance for Cyclone IV Devices (Part 1 of 2)
Performance
Device
EP4CE6
Unit
(1)
(1)
(1)
C6
C7
C8
C8L
C9L
265
I7
I8L
362
A7
500
500
500
500
500
500
437.5
437.5
437.5
437.5
437.5
437.5
402
402
402
402
402
402
362
362
362
362
362
362
437.5
437.5
437.5
437.5
437.5
437.5
402
402
402
402
402
402
MHz
MHz
MHz
MHz
MHz
MHz
EP4CE10
EP4CE15
EP4CE22
EP4CE30
EP4CE40
265
265
265
265
265
362
362
362
362
362
March 2016 Altera Corporation
Cyclone IV Device Handbook,
Volume 3
