System Address Map
3.7
Graphics Memory Address Ranges
The GMCH can be programmed to direct memory accesses to IGD when addresses are
within any of five ranges specified via registers in the GMCH’s Device 2 configuration
space.
1. The Memory Map Base Register (MMADR) is used to access graphics control
registers.
2. The Graphics Memory Aperture Base Register (GMADR) is used to access graphics
memory allocated via the graphics translation table.
3. The Graphics Translation Table Base Register (GTTADR) is used to access the
translation table.
4. The LT Graphics Memory Aperture Base Register (TGABAR) is used to access
protected graphics memory allocated via the graphics translation table.
5. The LT Graphics Translation Table Base Register (TGGTT) is used to access the
protected translation table.
These ranges can reside above the Top-of-Low-DRAM and below High BIOS and APIC
address ranges or above Top of upper DRAM (TOUUD). They MUST reside above the
top of memory (TOLUD) and below 4 GB or above TOUUD so they do not steal any
physical DRAM memory space.
GMADR is a Prefetchable range in order to apply USWC attribute (from the processor
point of view) to that range. The USWC attribute is used by the processor for write
combining.
3.8
System Management Mode (SMM)
System Management Mode uses main memory for System Management RAM (SMM
RAM). The GMCH supports: Compatible SMRAM (C_SMRAM), High Segment (HSEG),
and Top of Memory Segment (TSEG). System Management RAM space provides a
memory area that is available for the SMI handlers and code and data storage. This
memory resource is normally hidden from the system OS so that the processor has
immediate access to this memory space upon entry to SMM. GMCH provides three
SMRAM options:
•
•
Below 1 MB option that supports compatible SMI handlers.
Above 1 MB option that allows new SMI handlers to execute with write-back
cacheable SMRAM.
•
Optional TSEG area of 1 MB, 2 MB, or 8 MB in size. The TSEG area lies below IGD
stolen memory.
The above 1 MB solutions require changes to compatible SMRAM handlers code to
properly execute above 1 MB.
Note: DMI Interface and PCI Express masters are not allowed to access the SMM space.
