System Address Map
3.4
Main Memory Address Space (4 GB to TOUUD)
The G35 GMCH will support 36 bit addressing.
The maximum main memory size supported is 16 GB total DRAM memory. A hole
between TOLUD and 4 GB occurs when main memory size approaches 4 GB or larger.
As a result, TOM, and TOUUD registers and RECLAIMBASE/RECLAIMLIMIT registers
become relevant.
The new reclaim configuration registers exist to reclaim lost main memory space. The
greater than 32 bit reclaim handling will be handled similar to other GMCHs.
Upstream read and write accesses above 36-bit addressing will be treated as invalid
cycles by PEG and DMI.
Top of Memory
The “Top of Memory” (TOM) register reflects the total amount of populated physical
memory. This is NOT necessarily the highest main memory address (holes may exist
in main memory address map due to addresses allocated for memory mapped I/O
above TOM). TOM is used to allocate the Manageability Engine's stolen memory. The
Manageability Engine's (ME) stolen size register reflects the total amount of physical
memory stolen by the Manageability Engine. The ME stolen memory is located at the
top of physical memory. The ME stolen memory base is calculated by subtracting the
amount of memory stolen by the Manageability Engine from TOM.
The Top of Upper Usable Dram (TOUUD) register reflects the total amount of
addressable DRAM. If reclaim is disabled, TOUUD will reflect TOM minus Manageability
Engine's stolen size. If reclaim is enabled, then it will reflect the reclaim limit. Also,
the reclaim base will be the same as TOM minus ME stolen memory size to the nearest
64 MB alignment.
TOLUD register is restricted to 4 GB memory (A[31:20]), but G35 can support up to
16 GB, limited by DRAM pins. For physical memory greater than 4 GB, the TOUUD
register helps identify the address range in between the 4 GB boundary and the top of
physical memory. This identifies memory that can be directly accessed (including
reclaim address calculation) which is useful for memory access indication, early path
indication, and trusted read indication. When reclaim is enabled, TOLUD must be
64MB aligned, but when reclaim is disabled, TOLUD can be 1 MB aligned.
C1DRB3 cannot be used directly to determine the effective size of memory as the
values programmed in the DRBs depend on the memory mode (Flex memory mode,
interleaved). The Reclaim Base/Limit registers also can not be used because reclaim
can be disabled. The C0DRB3 register is used for memory channel identification
(channel 0 vs. channel 1) in the case of Flex memory mode operation.
