DRAM Controller Registers (D0:F0)
5.2.26
C1CKECTRL—Channel 1 CKE Control
B/D/F/Type:
Address Offset:
Default Value:
Access:
0/0/0/MCHBAR
660–663h
00000800h
RW/L, RW, RO
32 bits
Size:
This register provides Channel 1 CKE Controls.
Bit
Access &
Default
Description
31:30
RW
00b
Number of clocks from internal ODT command start that
ODT Read Safe will be asserted (sd1_cr_odt_rdsafe):
Number of clocks from internal ODT command start that ODT Read
Safe will be asserted
29:28
RW
00b
Number of clocks from internal ODT command start that
ODT Read Safe will be asserted (sd1_cr_odt_wrsafe):
Number of clocks from internal ODT command start that ODT Write
Safe will be asserted
27
RW
0b
start the self-refresh exit sequence (sd1_cr_srcstart): This
field indicates the request to start the self-refresh exit sequence.
26:24
RW
000b
CKE pulse width requirement in high phase
(sd1_cr_cke_pw_hl_safe): This field indicates CKE pulse width
requirement in high phase. This field corresponds to tCKE (high) in
the DDR Specification.
23
22
21
20
RW
0b
Rank 3 Population (sd1_cr_rankpop3):
1 = Rank 3 populated
0 = Rank 3 not populated.
RW
0b
Rank 2 Population (sd1_cr_rankpop2):
1 = Rank 2 populated
0 = Rank 2 not populated
RW
0b
Rank 1 Population (sd1_cr_rankpop1):
1 = Rank 1 populated
0 = Rank 1 not populated.
RW
0b
Rank 0 Population (sd1_cr_rankpop0):
1 = Rank 0 populated
0 = Rank 0 not populated
19:17
16
RW
000b
CKE pulse width requirement in low phase
(sd1_cr_cke_pw_lh_safe): This configuration register indicates
CKE pulse width requirement in low phase. This field corresponds
to tCKE (low) in the DDR Specification.
RW
0b
Enable CKE toggle for PDN entry/exit (sd1_cr_pdn_enable):
This configuration bit indicates that the toggling of CKEs (for PDN
entry/exit) is enabled.
