DRAM Controller Registers (D0:F0)
5.2.20
C1DRA01—Channel 1 DRAM Rank 0,1 Attributes
B/D/F/Type:
Address Offset:
Default Value:
Access:
0/0/0/MCHBAR
608–609h
0000h
RW
16 bits
Size:
The operation of this register is detailed in the description for register C0DRA01.
Bit
15:8
7:0
Access &
Default
Description
Channel 1 DRAM Rank-1 Attributes (C1DRA1): See C0DRA1
RW/L
00h
register.
Channel 1 DRAM Rank-0 Attributes (C1DRA0): See C0DRA0
RW/L
00h
register.
5.2.21
C1DRA23—Channel 1 DRAM Rank 2,3 Attributes
B/D/F/Type:
Address Offset:
Default Value:
Access:
0/0/0/MCHBAR
60A–60Bh
0000h
RW
16 bits
Size:
The operation of this register is detailed in the description for register C0DRA01.
Bit
15:8
7:0
Access &
Default
Description
RW/L
00h
Channel 1 DRAM Rank-3 Attributes (C1DRA3): See C0DRA3
register.
RW/L
00h
Channel 1 DRAM Rank-2 Attributes (C1DRA2): See C0DRA2
register.
Datasheet
131
