INTEL StrataFlash™ MEMORY TECHNOLOGY, 32 AND 64 MBIT
6.4
DC Characteristics
Sym
Parameter
Notes Typ
Max
Unit
Test Conditions
ILI
Input and VPEN Load
Current
1
±1
µA VCC = VCC Max
VIN = VCC or GND
ILO
Output Leakage
Current
1
±10
150
900
650
400
µA VCC = VCC Max
VIN = VCC or GND
ICCS
VCC Standby Current
1,3,5
80
µA CMOS Inputs, VCC = VCC Max,
CE0 = CE1 = CE2 = RP# = VCCQ1 ± 0.2 V
450
325
210
µA CMOS Inputs, RP# = VCC = VCC Max,
CE0 = CE1 = CE2 = VCCQ2 Min
µA CMOS Inputs, RP# = VCC = VCC Max,
CE2 = GND, CE0 = CE1 = VCCQ2 Min
µA CMOS Inputs, RP# = VCC = VCC Max,
CE1 = CE2 = GND, CE0 = VCCQ2 Min or
CE0 = CE2 = GND, CE1 = VCCQ2 Min
mA TTL Inputs, VCC = VCC Max,
0.71
80
2
CE0 = CE1 = CE2 = RP# = VIH
ICCD
ICCR
VCC Power-Down
Current
125
55
µA RP# = GND ± 0.2V
IOUT (STS) = 0 mA
VCC Read Current
1,5,6
35
mA CMOS Inputs, VCC = VCCQ =VCC Max
Device is enabled (see Table 2, Chip Enable
Truth Table)
f = 5 MHz
IOUT = 0 mA
45
65
mA TTL Inputs ,VCC = VCC Max
Device is enabled (see Table 2, Chip Enable
Truth Table)
f = 5 MHz
IOUT = 0 mA
ICCW VCC Program or Set
Lock-Bit Current
1,6,7
1,6,7
35
40
35
60
70
70
mA CMOS Inputs, VPEN = VCC
mA TTL Inputs, VPEN = VCC
mA CMOS Inputs, VPEN = VCC
ICCE
VCC Block Erase or
Clear Block Lock-Bits
Current
40
80
10
mA TTL Inputs, VPEN = VCC
ICCES VCC Block Erase
Suspend Current
1,2
mA Device is disabled (see Table 2, Chip Enable
Truth Table)
43
