Electrical Specifications
Figure 8. AC Test Circuit
VCC
VCC
Rload= 50 ohms
2.4nH
1.2pF
420 mils, 50 ohms, 169 ps/in
AC Timings test measurements made here.
Figure 9. TCK Clock Waveform
V2
V3
V1
tr = T56, T58 (Rise Time)
tf = T57, T59 (Fall Time)
tp = T55 (TCK Period)
V1,V2: For rise and fall times, TCK is measured
between 20% to 80% points on the waveform
V3: TCK is referenced to 0.5*Vcc
Mobile Intel Pentium 4 Processor-M Datasheet
41
