21150
Table 5. Secondary PCI Bus Interface Signals (Sheet 3 of 3)
Signal Name
Type
Description
Secondary PCI interface LOCK#. Signal s_lock_l is
deasserted during the first address phase of a transaction and
is asserted one clock cycle later by the 21150 when it is
propagating a locked transaction downstream. The 21150
does not propagate locked transactions upstream. The 21150
continues to assert s_lock_l until the address phase of the
next locked transaction, or until the lock is released. When the
lock is released, s_lock_l is driven to a deasserted state for
one cycle and then is sustained by an external pull-up resistor.
s_lock_l
STS
Secondary PCI interface PERR#. Signal s_perr_l is asserted
when a data parity error is detected for data received on the
secondary interface. The timing of s_perr_l corresponds to
s_par driven one cycle earlier and s_ad driven two cycles
earlier. Signal s_perr_l is asserted by the target during write
transactions, and by the initiator during read transactions.
When the secondary bus is idle, s_perr_l is driven to a
deasserted state for one cycle and then is sustained by an
external pull-up resistor.
s_perr_l
s_serr_l
STS
Secondary PCI interface SERR#. Signal s_serr_l can be
driven low by any device except the 21150 on the secondary
bus to indicate a system error condition. The 21150 samples
s_serr_l as an input and conditionally forwards it to the primary
bus on p_serr_l. The 21150 does not drive s_serr_l. Signal
s_serr_l is pulled up through an external resistor.
I
2.3
Secondary Bus Arbitration Signals
Table 6 describes the secondary bus arbitration signals.
Table 6. Secondary PCI Bus Interface Signals (Sheet 1 of 2)
Signal Name
Type
Description
Secondary PCI interface REQ#s. The 21150 accepts nine
request inputs, s_req_l<8:0>, into its secondary bus arbiter.
The 21150 request input to the arbiter is an internal signal.
Each request input can be programmed to be in either a high
priority rotating group or a low priority rotating group. An
asserted level on an s_req_l pin indicates that the
corresponding master wants to initiate a transaction on the
secondary PCI bus. If the internal arbiter is disabled (s_cfn_l
tied high), s_req_l<0> is reconfigured to be an external
secondary grant input for the 21150. In this case, an asserted
level on s_req_l<0> indicates that the 21150 can start a
transaction on the secondary PCI bus if the bus is idle.
s_req_l<8:0>
I
Secondary PCI interface GNT#s. The 21150 secondary bus
arbiter can assert one of nine secondary bus grant outputs,
s_gnt_l<8:0>, to indicate that an initiator can start a
transaction on the secondary bus if the bus is idle. The
21150’s secondary bus grant is an internal signal. A
programmable 2-level rotating priority algorithm is used. If the
internal arbiter is disabled (s_cfn_l tied high), s_gnt_l<0> is
reconfigured to be an external secondary bus request output
for the 21150. The 21150 asserts this signal whenever it wants
to start a transaction on the secondary bus.
s_gnt_l<8:0>
TS
Preliminary Datasheet
13
