OPTIREG™ SBC TLE9274QXV33

DC/DC regulators

6.2.3

External components

The buck converter needs one inductor and output capacitor filter. The inductor has a fixed value of 47 µH.

Secondary parameter such as saturation current must be selected based on the maximum current capability

needed in the application.

The output capacitors filter are 47 µF (typically, an electrolytic capacitor) in parallel with 10 µF (ceramic

capacitor). This configuration is intended for buck regulator functionality and keeps the total ESR lower than

1 Ω in all temperature range. For additional information, refer to Chapter 15.1.
