OPTIREG™ SBC TLE9274QXV33
Application information
Table 25 Bill of material for Figure 15.2
Ref.
Typical value
Purpose/comment
EMI filter components1)
C1
47 µF ±20%,
Input EMI filter capacitor, depending on the application
50 V electrolytic
L1
2.2 µH ±20%2)
Input EMI filter inductor, depending on the application
Input EMI filter capacitor, depending on the application
C2
4.7 µF ±20%,
50 V ceramic low ESR
Capacitances
CVSUP
C3
100 nF ±20% ceramic
Input filter battery capacitor for optimum EMC behavior
Input buck capacitor. Low ESR
1 µF…10 µF ±20%
ceramic
C4
C5
10 µF ±20%, 16 V ceramic 3) Output buck capacitor, for cost optimization. Low ESR
47 µF ±20%,
3) Output buck capacitor, for cost optimization. ESR 4 over the
16 V electrolytic
temperature range
CVCC2
C9
2.2 µF ±20% ceramic
10 nF ceramic
Blocking capacitor, min. 470 nF for stability. Low ESR
Spikes filtering, as required by application. Mandatory protection for off-
board connection
CVCAN
100 nF ± 20%,
16 V ceramic
Input filter CAN supply. The capacitor must be placed close to the VCAN
pin. One additional buffer capacitor 1 µF shall be placed for optimum
EMC and CAN FD performances
CCAN
CLIN1
CLIN2
CLIN3
CLIN4
47 nF / OEM dependent Split termination stability
1 nF / OEM dependent
1 nF / OEM dependent
1 nF / OEM dependent
1 nF / OEM dependent
LIN master termination
LIN master termination
LIN master termination
LIN master termination
Resistances
RCFG
R4
10 k…22 k±5%
Required for hardware initialization
10 k±5%
Wetting current of the switch, as required by application
Limit the WK pin current, e.g. for ISO pulses
CAN bus termination
R5
10 k±5%
RCANH
RCANL
RLIN1
RLIN2
RLIN3
RLIN4
60 / OEM dependent
60 / OEM dependent
1 k/ OEM dependent
1 k/ OEM dependent
1 k/ OEM dependent
1 k/ OEM dependent
CAN bus termination
LIN master termination (if configured as a LIN master)
LIN master termination (if configured as a LIN master)
LIN master termination (if configured as a LIN master)
LIN master termination (if configured as a LIN master)
Inductors
L2
47 µH ±20%2)
Buck regulator coil
Datasheet
123
Rev.2.0
2022-05-06
