OPTIREG™ SBC TLE9274QXV33
Package outlines
16
Package outlines
0.9 MAX.
(0.65)
11 x 0.5 = 5.5
0.5
±0.1
7
A
±0.03
0.1
6.8
+0.03 1)
2)
37
B
36
25
24
48x
0.08
48
13
1
12
Index Marking
48x
0.1
0.4 x 45°
±0.05
Index Marking
0.23
M
A B C
(0.2)
0.05 MAX.
(5.2)
(6)
C
1) Vertical burr 0.03 max., all sides
2) These four metal areas have exposed diepad potential
PG-VQFN-48-29, -31-PO V05
Figure 56 PG-VQFN-48 1)
Green Product (RoHS compliant)
To meet the world-wide customer requirements for environmentally friendly products and to be compliant
with government regulations the device is available as a green product. Green products are RoHS-Compliant
(i.e Pb-free finish on leads and suitable for Pb-free soldering according to IPC/JEDEC J-STD-020).
Further information on packages
https://www.infineon.com/packages
1) Dimensions in mm
Datasheet
127
Rev.2.0
2022-05-06
