TLD7002-16ES

Datasheet

3 General product characteristics

3.2

Functional range

Table 3

Functional range

T_J= -40°C to +150°C, all voltages with respect to ground, positive currents flowing as described in Figure 2 (unless

otherwise specified)

Parameter

Symbol

Values

Typ.

Unit

Note or condition

P-

Number

Min.

Max.

Supply pins

Power supply voltage V_SOP

–

PRQ-373

PRQ-763

operating range

Extended power

supply voltage

operating range

V_SOPEXT

t ≤ 1 min with

parameter deviations

Digital supply output

voltage

V_DD

4.5

5.5

–

PRQ-372

VS capacitor range

VDD capacitor range

VLED capacitor range

Temperatures

C_VS

100

4700

–

470

–

X7R

PRQ-374

PRQ-375

PRQ-376

C_VDD

C_VLED

13000

–

470

X7R

–

Junction temperature T_J

Output stage

-40

–

150

°C

PRQ-377

VLED operating range V_LED(OP)

–

PRQ-660

PRQ-378

Output voltage

operating range

V_OUT(OP)

0.6

Output current per

channel

I_OUT

–

76.5

Code 0x00 = 5.625

mA, Code 0x3F = 76.5

mA;

PRQ-379

OUT.DC = 0 ꢀ results

into 0 mA and power

stage is oﬀ.

Output capacitor range C_OUT

–

100

–

PRQ-380

Output inductance

range

L_OUT

μH

10 nF < C_OUT≤ 100 nF PRQ-381

Output inductance

range

L_OUT

–

µH

C_OUT< 10 nF PRQ-382

Datasheet

Rev.1.00

2022-05-03
