TLD7002-16ES 参数 Datasheet PDF下载

型号：	TLD7002-16ES
PDF下载：	下载PDF文件查看货源
内容描述：	[The TLD7002-16ES is a 16 channel device with integrated and protected output stages. It is designed to control LEDs with a current up to 76.5 mA as linear current sink (LCS). The power stages can be configured in parallel for higher load currents. Each individual power output stage is configured to a 6-bit current set value stored in the OTP. 16 independent and individual PWM configurations can be set. A high-speed lighting interface is used for device OTP programming, configuration, control and]
分类和应用：
文件页数/大小：	82 页 / 3105 K
品牌：	INFINEON [ Infineon ]

TLD7002-16ES

Datasheet

3 General product characteristics

General product characteristics

3.1

Absolute maximum ratings

Table 2

Absolute maximum ratings

T_J= -40°C to +150°C; all voltages with respect to ground, positive currents flowing as described in Figure 2 (unless

otherwise specified).

Parameter

Symbol

Values

Typ.

Unit

Note or condition

P-

Number

Min.

Max.

Supply pins

Power supply voltage V_S

-0.3

–

PRQ-362

PRQ-686

Power supply load

dump voltage

V_S(LD)

–

suppressed Load

Dump acc. to

ISO16750-2 (2010). R_i=

2 Ω

Digital supply voltage V_DD

Digital supply current I_DD

-0.3

–

5.5

–

PRQ-363

PRQ-364

Not subject to

production test -

specified by design

Output pins

Power output voltage V_OUT

Power output current I_OUT

-0.3

–

PRQ-365

PRQ-366

Not subject to

production test -

specified by design

GPIN/VLED pins

Voltage at pin GPIN0,

GPIN1

V_GPIN

I_GPIN

-0.3

–

VDD

–

PRQ-367

PRQ-368

Current at pin GPIN0,

GPIN1

Not subject to

production test -

specified by design

Voltage at pin VLED

V_LED

-0.3

-27

–

PRQ-369

PRQ-756

HSLI pins

Voltage at pin HSLIL,

HSLIH

V_HSLI

Temperatures

Junction temperature T_J

-40

–

150

°C

Not subject to

production test -

specified by design

PRQ-370

(table continues...)

Datasheet

Rev.1.00

2022-05-03
