8)
This specification is valid during Reset and during Hold-mode or Adapt-mode. During Hold-mode Port 6 pins
are only affected, if they are used (configured) for CS output and the open drain function is not enabled. The
READY-pullup is always active, except for Powerdown mode.
9)
This specification is valid during Reset and during Adapt-mode.
Not 100% tested, guaranteed by design and characterization.
10)
Power Consumption C167CR
(Operating Conditions apply)
Parameter
Symbol
Limit Values
min. max.
15 + 2.5 × mA RSTIN = VIL
CPU in [MHz]1)
Unit Test Condition
Power supply current (active) IDD
with all peripherals active
–
–
–
fCPU
f
Idle mode supply current
IID
10 + 1.0 × mA RSTIN = VIH1
fCPU
f
CPU in [MHz]1)
2)
Power-down mode supply
current
IPD
50
µA
VDD = VDDmax
1)
The supply current is a function of the operating frequency. This dependency is illustrated in Figure 8.
These parameters are tested at VDDmax and maximum CPU clock with all outputs disconnected and all inputs
at VIL or VIH.
2)
This parameter is tested including leakage currents. All inputs (including pins configured as inputs) at 0 V to
0.1 V or at VDD - 0.1 V to VDD, all outputs (including pins configured as outputs) disconnected.
