C167CR
C167SR
Operating Conditions
The following operating conditions must not be exceeded in order to ensure correct
operation of the C167CR. All parameters specified in the following sections refer to these
operating conditions, unless otherwise noticed.
Table 9
Operating Condition Parameters
Symbol Limit Values Unit Notes
min. max.
4.5 5.5
Parameter
Digital supply voltage
VDD
V
Active mode,
CPUmax = 33 MHz
f
2.51) 5.5
0
V
V
Power Down mode
Digital ground voltage
Overload current
VSS
IOV
Reference voltage
–
–
5
mA Per pin 2)3)
3)
Absolute sum of overload Σ|IOV|
currents
50
mA
External Load Capacitance CL
–
–
–
50
pF
pF
pF
Pin drivers in
fast edge mode
(PDCR.BIPEC = ‘0’)
30
Pin drivers in
reduced edge mode
(PDCR.BIPEC = ‘1’)3)
100
Pin drivers in
fast edge mode,
f
CPUmax = 25 MHz4)
Ambient temperature
TA
0
70
°C
°C
°C
SAB-C167CR …
SAF-C167CR …
SAK-C167CR …
-40
-40
85
125
1)
Output voltages and output currents will be reduced when VDD leaves the range defined for active mode.
2)
Overload conditions occur if the standard operatings conditions are exceeded, i.e. the voltage on any pin
exceeds the specified range (i.e. VOV > VDD + 0.5 V or VOV < VSS - 0.5 V). The absolute sum of input overload
currents on all pins may not exceed 50 mA. The supply voltage must remain within the specified limits.
Proper operation is not guaranteed if overload conditions occur on functional pins like XTAL1, RD, WR, etc.
3)
4)
Not 100% tested, guaranteed by design and characterization.
The increased capacitive load is valid for the 25 MHz-derivatives up to a CPU clock frequency of 25 MHz.
Under these circumstances the timing parameters as specified in the “C167CR Data Sheet 1999-06” are valid.
Data Sheet
44
V3.2, 2001-07
