CoolSET®-F3R
ICE3BR0665JF
Functional Description
3.5.3
Gate Driver
3.6
Current Limiting
PWM Latch
FF1
VCC
Current Limiting
PWM-Latch
1
Propagation-Delay
Compensation
Gate
CoolMOS®
Vcsth
Leading
Edge
C10
Blanking
220ns
PWM-OP
Gate Driver
&
C12
G10
Figure 15
Gate Driver
0.26V
The driver-stage is optimized to minimize EMI and to
provide high circuit efficiency. This is done by reducing
the switch on slope when exceeding the internal
CoolMOS® threshold. This is achieved by a slope
control of the rising edge at the driver’s output (see
Figure 9).
1pF
10k
Active Burst
Mode
D1
CS
(internal)
VGate
Figure 17
Current Limiting Block
There is a cycle by cycle peak current limiting operation
realized by the Current-Limit comparator C10. The
source current of the integrated CoolMOS® is sensed
via an external sense resistor RSense. By means of
RSense the source current is transformed to a sense
voltage VSense which is fed into the pin CS. If the voltage
VSense exceeds the internal threshold voltage Vcsth, the
comparator C10 immediately turns off the gate drive by
resetting the PWM Latch FF1.
ca. t = 130ns
5V
A Propagation Delay Compensation is added to
support the immediate shut down of the integrated
CoolMOS® with very short propagation delay. Thus the
influence of the AC input voltage on the maximum
output power can be reduced to minimal.
In order to prevent the current limit from distortions
caused by leading edge spikes, a Leading Edge
Blanking is integrated in the current sense path for the
comparators C10, C12 and the PWM-OP.
The output of comparator C12 is activated by the Gate
G10 if Active Burst Mode is entered. When it is
activated, the current limiting is reduced to 0.26V. This
voltage level determines the maximum power level in
Active Burst Mode.
t
Figure 16
Gate Rising Slope
Thus the leading switch on spike is minimized.
Furthermore the driver circuit is designed to eliminate
cross conduction of the output stage.
During power up, when VCC is below the undervoltage
lockout threshold VVCCoff, the output of the Gate Driver
is set to low in order to disable power transfer to the
secondary side.
Version 2.0
13
11 Sep 2008
