High Current PN Half Bridge
BTN8982TA
Block Description and Characteristics
5
Block Description and Characteristics
5.1
Supply Characteristics
VS = 8 V to 18 V, Tj = -40 °C to +150 °C, IL = 0 A, all voltages with respect to ground, positive current flowing into pin
(unless otherwise specified)
Pos.
Parameter
Symbol
Limit Values
Unit
Conditions
Min.
Typ.
Max.
General
5.1.1
Supply Current
IVS(on)
–
2.2
3.3
mA
V
INH = 5 V
VIN = 0 V or 5 V
SR = 0 Ω
R
DC-mode
normal operation
(no fault condition)
5.1.2
Quiescent Current
IVS(off)
–
–
7
–
13
75
µA
µA
VINH = 0 V
VIN = 0 V or 5 V
Tj < 85 °C 1)
V
INH = 0 V
VIN = 0 V or 5 V
1) Not subject to production test, specified by design
Vs = 18V
Vs = 14V
Vs = 8V
[°C]
T
Figure 5
Typical Quiescent Current vs. Junction Temperature
Data Sheet
9
Rev. 1.0, 2013-05-17
