High Current PN Half Bridge
BTN8982TA
Block Description and Characteristics
5.2.2
Switching Times
IN
t
tdr(HS) tr(HS)
tdf(HS) tf(H S)
V
OUT
80%
80%
ΔVOUT
ΔVOUT
20%
20%
t
Figure 7
Definition of switching times high side (Rload to GND)
IN
t
tdf(LS) tf(LS)
tr(LS)
tdr(LS)
V
OUT
80%
80%
ΔVOUT
ΔVOUT
20%
20%
t
Figure 8
Definition of switching times low side (Rload to VS)
Due to the timing differences for the rising and the falling edge there will be a slight difference between the length
of the input pulse and the length of the output pulse. It can be calculated using the following formulas:
•
•
ΔtHS = (tdr(HS) + 0.5 tr(HS)) - (tdf(HS) + 0.5 tf(HS)
ΔtLS = (tdf(LS) + 0.5 tf(LS)) - (tdr(LS) + 0.5 tr(LS)).
)
