AN985B/BX
Registers and Descriptors Description
Current Working Transmit Descriptor Pointer
WTDP_CSR21
Current Working Transmit Descriptor Pointer
Offset
94H
Reset Value
xxxx xxxxH
ꢀꢁ ꢀꢂ ꢃꢄ ꢃꢅ ꢃꢆ ꢃꢇ ꢃꢈ ꢃꢉ ꢃꢀ ꢃꢃ ꢃꢁ ꢃꢂ ꢁꢄ ꢁꢅ ꢁꢆ ꢁꢇ ꢁꢈ ꢁꢉ ꢁꢀ ꢁꢃ ꢁꢁ ꢁꢂ ꢄ
ꢅ ꢆ ꢇ ꢈ ꢉ ꢀ ꢃ ꢁ ꢂ
:7'3
UR
Field
Bits
Type
Description
WTDP
31:0
ro
Working Transmit Descriptor Pointer
The current working transmit descriptor pointer for driver’s double-
checking or other special purpose.
Current Working Receive Descriptor Pointer
WRDP_CSR22
Current Working Receive Descriptor Pointer
Offset
98H
Reset Value
xxxx xxxxH
ꢀꢁ ꢀꢂ ꢃꢄ ꢃꢅ ꢃꢆ ꢃꢇ ꢃꢈ ꢃꢉ ꢃꢀ ꢃꢃ ꢃꢁ ꢃꢂ ꢁꢄ ꢁꢅ ꢁꢆ ꢁꢇ ꢁꢈ ꢁꢉ ꢁꢀ ꢁꢃ ꢁꢁ ꢁꢂ ꢄ
ꢅ ꢆ ꢇ ꢈ ꢉ ꢀ ꢃ ꢁ ꢂ
:5'3
UR
Field
Bits
Type
Description
WRDP
31:0
ro
Working Receive Descriptor Pointer
The current working receive descriptor pointer for driver’s double-
checking or other special purpose.
Data Sheet
72
Rev. 1.51, 2005-11-30
