IDT72T7285/72T7295/72T72105/72T72115 2.5V TeraSync
16,384 x 72, 32,768 x 72, 65,536 x 72, 131,072 x 72
72-BIT FIFO
COMMERCIAL AND INDUSTRIAL
TEMPERATURE RANGES
TheStandardJTAGinterfaceconsistsoffourbasicelements:
JTAGINTERFACE
•
•
•
•
Test Access Port (TAP)
TAPcontroller
Instruction Register (IR)
Data Register Port (DR)
Five additional pins (TDI, TDO, TMS, TCK and TRST) are provided to
support the JTAG boundary scan interface. The IDT72T7285/72T7295/
72T72105/72T72115incorporatesthenecessarytapcontrollerandmodified
padcellstoimplementtheJTAG facility.
NotethatIDTprovidesappropriateBoundaryScanDescriptionLanguage
programfilesforthesedevices.
Thefollowingsectionsprovideabriefdescriptionofeachelement. Fora
completedescriptionrefertotheIEEEStandardTestAccessPortSpecification
(IEEEStd. 1149.1-1990).
The Figure belowshows the standardBoundary-ScanArchitecture
DeviceID Reg.
Mux
Boundary Scan Reg.
Bypass Reg.
TDO
TDI
T
A
clkDR, ShiftDR
UpdateDR
TMS
P
TAP
TCLK
Cont-
roller
TRST
Instruction Decode
clklR, ShiftlR
UpdatelR
Instruction Register
Control Signals
5994 drw12
Figure 7. Boundary Scan Architecture
TEST ACCESS PORT (TAP)
THETAPCONTROLLER
The Tap interface is a general-purpose port that provides access to the
TheTapcontrollerisasynchronousfinitestatemachinethatrespondsto
internaloftheprocessor. Itconsistsoffourinputports(TCLK,TMS,TDI,TRST) TMSandTCLKsignalstogenerateclockandcontrolsignalstotheInstruction
and one output port (TDO).
andDataRegisters forcaptureandupdateofdata.
