FT2232C Dual USB UART / FIFO I.C.
9.3 245 FIFO Interface Mode Signal Descriptions and Configuration
When either Channel A or Channel B are in 245 FIFO mode the IO signal lines are configured as follows.
FIFO DATA BUS GROUP **Note 17
Pin#
Signal
Type
Description
Channel A Channel B
24
23
22
21
20
19
17
16
40
39
38
37
36
35
33
32
D0
D1
D2
D3
D4
D5
D6
D7
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
FIFO Data Bus Bit 0
FIFO Data Bus Bit 1
FIFO Data Bus Bit 2
FIFO Data Bus Bit 3
FIFO Data Bus Bit 4
FIFO Data Bus Bit 5
FIFO Data Bus Bit 6
FIFO Data Bus Bit 7
FIFO CONTROL INTERFACE GROUP
Pin#
Signal
Type
Description
Channel A Channel B
15
30
RXF#
OUTPUT When high, do not read data from the FIFO. When low, there is
data available in the FIFO which can be read by strobing RD#
low then high again ** Note 18
13
12
29
28
TXE#
RD#
OUTPUT When high, do not write data into the FIFO. When low, data can
be written into the FIFO by strobing WR high then low. ** Note 18
INPUT
Enables Current FIFO Data Byte on D0..D7 when low. Fetches
the next FIFO Data Byte (if available) from the Receive FIFO
Buffer when RD# goes from low to high. ** Note 17
11
10
27
26
WR
INPUT
INPUT
Writes the Data Byte on the D0..D7 into the Transmit FIFO Buffer
when WR goes from high to low. ** Note 17
SI/WU
The Send Immediate / WakeUp signal combines two functions
on a single pin. If USB is in suspend mode (PWREN# = 1) and
remote wakeup is enabled in the EEPROM , strobing this pin
low will cause the device to request a resume on the USB Bus.
Normally, this can be used to wake up the Host PC.
During normal operation (PWREN# = 0), if this pin is strobed low
any data in the device TX buffer will be sent out over USB on the
next Bulk-IN request from the drivers regardless of the pending
packet size. This can be used to optimise USB transfer speed for
some applications. Tie this pin to VCCIO if not used.
**Note 17 : In Input Mode, these pins are pulled to VCCIO via internal 200K resistors. These can be programmed to
gently pull low during USB suspend ( PWREN# = “1” ) by setting this option in the EEPROM.
**Note 18 : During device reset, these pins are tri-state but pulled up to VCCIO via internal 200K resistors.
