Phase Lock Loop (PLL) Characteristics
Table 3-5 Clock Operation (continued)
Characteristics Symbol
ETC
No.
Min
Max
4
EXTAL cycle time2
• With PLL disabled
• With PLL enabled
6.7 ns
6.7 ns
∞
273.1 µs
4
7
Instruction cycle time = ICYC = TC
• With PLL disabled
ICYC
13.33 ns
6.67 ns
∞
• With PLL enabled
8.53 µs
1
2
3
Measured at 50% of the input transition.
The maximum value for PLL enabled is given for minimum VCO and maximum MF.
The indicated duty cycle is for the specified maximum frequency for which a part is rated. The minimum clock high or low time
required for correct operation, however, remains the same at lower operating frequencies; therefore, when a lower clock
frequency is used, the signal symmetry may vary from the specified duty cycle as long as the minimum high time and low time
requirements are met.
4
The maximum value for PLL enabled is given for minimum VCO and maximum DF.
3.8
Phase Lock Loop (PLL) Characteristics
Table 3-6 PLL Characteristics
Characteristics
Min
Max
Unit
MHz
pF
V
CO frequency when PLL enabled (MF × Ef × 2/PDF)
30
300
1)
PLL external capacitor (PCAP pin to VCCP) (CPCAP
• @ MF ≤ 4
(MF × 580) − 100
MF × 830
(MF × 780) − 140
MF × 1470
• @ MF > 4
1
CPCAP is the value of the PLL capacitor (connected between the PCAP pin and VCCP). The recommended value in pF for
CPCAP can be computed from one of the following equations:
(MF x 680)-120, for MF ≤ 4, or
MF x 1100, for MF > 4.
DSP56367 Technical Data, Rev. 2.1
3-6
Freescale Semiconductor
