Table 2-2 Signal and Package Information for the 128-Pin LQFP
State
During
Reset
Signal
Name
Pin No.
Type
Signal Description
CAN_TX
120
Open
Drain
Open
Drain
FlexCAN Transmit Data — CAN output with internal pull-up
enable at reset.*
Output
Output
* Note: If a pin is configured as open drain output mode, internal
pull-up will automatically be disabled when it outputs low.
Internal pull-up will be enabled unless it has been manually
disabled by clearing the corresponding bit in the PUREN register
of the GPIO module, when it outputs high.
If a pin is configured as push-pull output mode, internal pull-up
will automatically be disabled, whether it outputs low or high.
TC0
111
113
Schmitt
Input/
Output
Input,
pull-up
enabled
TC0 - 1 — Timer C, Channels 0 and 1
(GPIOE8)
Schmitt
Input/
Output
Port E GPIO — These GPIO pins can be individually
programmed as input or output pins.
TC1
(GPIOE9)
At reset, these pins default to Timer functionality.
To deactivate the internal pull-up resistor, clear the appropriate
bit of the GPIOE_PUR register. See Part 6.5.6 for details.
TD0
107
Schmitt
Input/
Output
Input,
pull-up
enabled
TD0 - TD3 — Timer D, Channels 0, 1, 2 and 3
(GPIOE10)
Schmitt
Input/
Output
Port E GPIO — These GPIO pins can be individually
programmed as input or output pins.
TD1
(GPIOE11)
108
109
110
At reset, these pins default to Timer functionality.
TD2
(GPIOE12)
To deactivate the internal pull-up resistor, clear the appropriate
bit of the GPIOE_PUR register. See Part 6.5.6 for details.
TD3
(GPIOE13)
IRQA
IRQB
52
53
Schmitt
Input
Input,
pull-up
enabled
External Interrupt Request A and B — The IRQA and IRQB
inputs are asynchronous external interrupt requests during Stop
and Wait mode operation. During other operating modes, they
are synchronized external interrupt requests, which indicate an
external device is requesting service. They can be programmed
to be level-sensitive or negative-edge triggered.
To deactivate the internal pull-up resistor, set the IRQ bit in the
SIM_PUDR register. See Part 6.5.6 for details.
56F8345 Technical Data, Rev. 17
34
Freescale Semiconductor
Preliminary
