Register Descriptions
6.3.3
SIM Software Control Registers (SIM_SWC0, SIM_SWC1,
SIM_SWC2, and SIM_SWC3)
These registers are general-purpose registers. They are reset only at power-on, so they can monitor
software execution flow.
Base + $2
Read
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Software Control Data 0 - 3
Write
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
RESET
Figure 6-4 SIM Software Control Register 0 (SIM_SWC0 - 3)
Software Control Register 0 - 3 (FIELD)—Bits 15–0
6.3.3.1
This register is reset only by the Power-On Reset (POR). It is intended for use by a software developer to
contain data that will be unaffected by the other reset sources (external reset, software reset, and COP
reset).
6.3.4
Most Significant Half of JTAG ID (SIM_MSHID)
This read-only register displays the most significant half of the JTAG ID for the chip. This register reads
$01F2.
Base + $6
Read
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0
0
0
0
0
0
0
1
1
1
1
1
0
0
1
0
Write
RESET
0
0
0
0
0
0
0
1
1
1
1
1
0
0
1
0
Figure 6-5 Most Significant Half of JTAG ID (SIM_MSHID)
6.3.5
Least Significant Half of JTAG ID (SIM_LSHID)
This read-only register displays the least significant half of the JTAG ID for the chip. This register reads
$801D.
Base + $7
Read
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
1
0
0
0
0
0
0
0
0
0
0
1
1
1
0
1
Write
1
0
0
0
0
0
0
0
0
0
0
1
1
1
0
1
RESET
Figure 6-6 Least Significant Half of JTAG ID (SIM_LSHID)
