5.6.2.4
MSCAN Receive Interrupt Priority Level (MSCAN_RX IPL)—Bits 9–8
This field is used to set the interrupt priority level for MSCAN Receive IRQ. This IRQ is limited to
priorities 0 through 2. It is disabled by default.
•
•
•
•
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
5.6.2.5
MSCAN Error Interrupt Priority Level (MSCAN_ERR IPL)—Bits 7–6
This field is used to set the interrupt priority level for the MSCAN Error IRQ. This IRQ is limited to
priorities 0 through 2. It is disabled by default.
•
•
•
•
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
5.6.2.6
FM Command, Data, Address Buffers Empty Interrupt Priority Level
(FM_CBE IPL)—Bits 5–4
This field is used to set the interrupt priority level for the FM Command, Data Address Buffers Empty
IRQ. This IRQ is limited to priorities 0 through 2. It is disabled by default.
•
•
•
•
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
5.6.2.7
FM Command Complete Interrupt Priority Level (FM_CC IPL)—Bits 3–2
This field is used to set the interrupt priority level for the FM Command Complete IRQ. This IRQ is
limited to priorities 0 through 2. It is disabled by default.
•
•
•
•
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
5.6.2.8
FM Error Interrupt Priority Level (FM_ERR IPL)—Bits 1–0
This field is used to set the interrupt priority level for the FM Error IRQ. This IRQ is limited to priorities
0 through 2. It is disabled by default.
•
•
•
•
00 = IRQ disabled (default)
01 = IRQ is priority level 0
10 = IRQ is priority level 1
11 = IRQ is priority level 2
