56F8014 Signal Pins
Table 2-3 56F8014 Signal and Package Information for the 32-Pin LQFP (Continued)
Signal
Name
LQFP
Pin No.
StateDuring
Reset
Type
Signal Description
ANB1
5
Input
Analog
Input
ANB1 — Analog input to ADC B, channel 1
(GPIOC5)
Input/
Port C GPIO — This GPIO pin can be individually programmed as
Output
an input or output pin.
After reset, the default state is ANB1.
ANB2
6
Input
Input
Analog
Input
ANB2 — Analog input to ADC B, channel 2
(VREFL
)
VREFL — Analog reference voltage low. This should normally be
connected to a low-noise VSS
.
Input/
Output
(GPIOC6)
Port C GPIO — This GPIO pin can be individually programmed as
an input or output pin.
After reset, the default state is ANB2.
ANB3
7
Input
Analog
Input
ANB3 — Analog input to ADC B, channel 3
(GPIOC7)
Input/
Port C GPIO — This GPIO pin can be individually programmed as
Output
an input or output pin.
After reset, the default state is ANB3.
Return to Table 2-2
56F8014 Technical Data, Rev. 9
Freescale Semiconductor
Preliminary
25
