56F8014 Signal Pins
Table 2-3 56F8014 Signal and Package Information for the 32-Pin LQFP (Continued)
Signal
Name
LQFP
Pin No.
StateDuring
Reset
Type
Signal Description
GPIOA1
(PWM1)
GPIOA2
(PWM2)
GPIOA4
27
23
22
Input/
Output
Output
Port A GPIO — This GPIO pin can be individually programmed as
disabled, an input or output pin.
internal
pull-up
enabled,
pin is in input
mode
Output
PWM1 — This is one of the six PWM output pins.
After reset, the default state is GPIOA1.
Input/
Output
Output
Port A GPIO — This GPIO pin can be individually programmed as
disabled, an input or output pin.
internal
pull-up
enabled,
pin is in input
mode
Output
PWM2 — This is one of the six PWM output pins.
After reset, the default state is GPIOA2.
Input/
Output
Port A GPIO — This GPIO pin can be individually programmed as
Output
disabled, an input or output pin.
internal
pull-up
(PWM4)
Output
Input
enabled,
pin is in input
mode
PWM4 — This is one of the six PWM output pins.
(FAULT1)
Fault1 — This fault input pin is used for disabling selected PWM
outputs in cases where fault conditions originate off-chip.
(T27)
Input/
Output
T2 — Timer, Channel 2
After reset, the default state is GPIOA4. The peripheral functionality
is controlled via the SIM. See Section 6.3.8.
7. This signal is also brought out on the GPIOB2 pin.
GPIOA5
20
Input/
Output
Port A GPIO — This GPIO pin can be individually programmed as
Output
disabled, an input or output pin.
internal
pull-up
(PWM5)
Output
enabled,
pin is in input
mode
PWM5 — This is one of the six PWM output pins.
(FAULT2)
Input/
Fault2 — This fault input pin is used for disabling selected PWM
Output
outputs in cases where fault conditions originate off-chip.
T3 — Timer, Channel 3
(T38)
Input/
After reset, the default state is GPIOA5. The peripheral functionality
Output
is controlled via the SIM. See Section 6.3.8.
8. This signal is also brought out on the GPIOB3 pin.
Return to Table 2-2
56F8014 Technical Data, Rev. 9
Freescale Semiconductor
Preliminary
23
