10.10 Quad Timer Timing
1, 2
Table 10-15 Timer Timing
Characteristic
Timer input period
Symbol
PIN
Min
2T + 6
1T + 3
125
Max
—
Unit
ns
See Figure
10-11
Timer input high / low period
Timer output period
PINHL
POUT
—
ns
10-11
—
ns
10-11
Timer output high / low period
POUTHL
50
—
ns
10-11
1. In the formulas listed, T = the clock cycle. For 32MHz operation, T = 31.25ns.
2. Parameters listed are guaranteed by design.
Timer Inputs
PINHL
PINHL
PIN
Timer Outputs
POUTHL
POUTHL
POUT
Figure 10-11 Timer Timing
56F8014 Technical Data, Rev. 9
104
Freescale Semiconductor
Preliminary
