EMD3D256M08BS1
EMD3D256M16BS1
THERMAL CHARACTERISTICS
Table 6 – Thermal Characteristics 78-ball BGA Package
Symbol Parameter
Value
Unit
TOPER
ΘJA
Maximum Operating Temperature
Thermal Resistance Junction to Ambient
Thermal Resistance Junction to Case
0 to 85
26.4
°C
°C/watt
°C/watt
ΘJC
2.3
Table 7 – Thermal Characteristics 96-ball BGA Package
Symbol Parameter
Value
Unit
TOPER
ΘJA
Maximum Operating Temperature
0 to 85
25.6
°C
Thermal Resistance Junction to Ambient
Thermal Resistance Junction to Case
°C/watt
°C/watt
ΘJC
2.3
EMD3D256M08BS1/16BS1 Revision 1.3 10/2018
Copyright © 2018 Everspin Technologies
