EMD3D256M08BS1
EMD3D256M16BS1
ABSOLUTE MAXIMUM RATINGS
Table 5 – Absolute Maximum Ratings
Min
Symbol Parameter
Max
Unit
Notes
VDD
VDD supply voltage relative to VSS
VDDQ
VIN, VOUT
TOPER
-0.4
1.975
V
1
VDD supply voltage relative to VSSQ
Voltage on any pin relative to VSS
Normal operating temperature
Storage temperature
0
85
°C
°C
2
-
TSTG
-55
150
Hmax
Maximum magnetic field during read, write, standby or
power off.
-
2,000
A/m
Notes:
1. VDD and VDDQ must be within 300mV of each other at all times, and VREF must not be greater than 0.6 × VDDQ
VDDQ are <500mV, VREF can be ≤300mV.
.
When VDD and
2. The normal temperature range specifies the temperature at which all STT-MRAM specifications will be supported. During
operation, the STT-MRAM case temperature must be maintained between 0°C to 85°C under all operating conditions.
EMD3D256M08BS1/16BS1 Revision 1.3 10/2018
Copyright © 2018 Everspin Technologies
15
