ZSPM1025A
True Digital PWM Controller (Single-Phase, Single-Rail)
Figure 3.2
Power Sequencing
VOUTnom
0 V
t
tON_DELAY
tON_RISE
tOFF_DELAY
tOFF_FALL
OPERATION_ON
Control pin
OPERATION_OFF
Control pin
tON_MAX
tOFF_MAX
3.3.5.
Pre-biased Start-up and Soft Stop
Dedicated pre-biased start-up logic ensures proper start-up of the power converter when the output capacitors are
pre-charged to a non-zero output voltage. Closed-loop stability is ensured during this phase.
The ZSPM1025A also supports pre-biased off, i.e. the output voltage is not ramped down to zero and instead
remains at a predefined level (VOFF_nom). This value can be configured via the Pink Power Designer™. After
receiving the shutdown command via the PMBus™ or the CONTROL pin, the ZSPM1025A ramps down the
output voltage value to the predefined value. Once the value is reached, the PWM output will be put into tri-state
mode in order to put the output driver into its tri-state mode.
Figure 3.3
Power Sequencing with Non-zero Off Voltage
VONnom
Tri-state
VOFFnom
0 V
t
tON_DELAY
tON_RISE
tOFF_DELAY
tOFF_FALL
tON_MAX
tOFF_MAX
