ZSPM1025A
True Digital PWM Controller (Single-Phase, Single-Rail)
2.3. Available Packages
The ZSPM1025A is available in a 24-pin QFN package. The pin-out is shown in Figure 2.3. The mechanical
drawing of the package can be found in Figure 6.1.
Figure 2.3
Pin-out QFN24 Package
24 23
21 20 19
22
1
2
3
4
5
6
AGND
SCL
SDA
18
17
16
15
14
13
VREFP
VFBP
SMBALERT
GPIO0
PAD
VFBN
ISNSP
ISNSN
CONTROL
PGOOD
7
8
9
10 11 12
