DA14580
FINAL
Bluetooth Low Energy 4.2 SoC
Table 166: GPIO_IRQ0_IN_SEL_REG (0x50001400)
Bit
Mode Symbol
R/W KBRD_IRQ0_SEL
Description
Reset
5:0
input selection that can generate a GPIO interrupt
0: no input selected
1: P0[0] is selected
0x0
2: P0[1] is selected
3: P0[2] is selected
4: P0[3] is selected
5: P0[4] is selected
6: P0[5] is selected
7: P0[6] is selected
8: P0[7] is selected
9: P1[0] is selected
10: P1[1] is selected
11: P1[2] is selected
12: P1[3] is selected
13: P1[4] is selected
14: P1[5] is selected
15: P2[0] is selected
16: P2[1] is selected
17: P2[2] is selected
18: P2[3] is selected
19: P2[4] is selected
20: P2[5] is selected
21: P2[6] is selected
22: P2[7] is selected
23: P2[8] is selected
24: P2[9] is selected
25: P3[0] is selected
26: P3[1] is selected
27: P3[2] is selected
28: P3[3] is selected
29: P3[4] is selected
30: P3[5] is selected
31: P3[6] is selected
32: P3[7] is selected
all others: no input selected
Table 167: GPIO_IRQ1_IN_SEL_REG (0x50001402)
Bit
Mode Symbol
Description
Reset
0x0
15:5
5:0
-
-
Reserved
R/W
KBRD_IRQ1_SEL
see KBRD_IRQ0_SEL
0x0
Table 168: GPIO_IRQ2_IN_SEL_REG (0x50001404)
Bit
Mode Symbol
Description
Reset
0x0
15:5
5:0
-
-
Reserved
R/W
KBRD_IRQ2_SEL
see KBRD_IRQ0_SEL
0x0
Table 169: GPIO_IRQ3_IN_SEL_REG (0x50001406)
Bit
Mode Symbol
Description
Reset
0x0
15:5
5:0
-
-
Reserved
R/W
KBRD_IRQ3_SEL
see KBRD_IRQ0_SEL
0x0
Datasheet
Revision 3.4
09-Nov-2016
CFR0011-120-01
112 of 155
