Table 157: I2C_STATUS_REG (0x50001370)
Bit
Mode Symbol
I2C_ACTIVITY
Description
Reset
0
R
I2C Activity Status.
0x0
Table 158: I2C_TXFLR_REG (0x50001374)
Bit
Mode Symbol
Description
Reset
0x0
15:6
5:0
-
-
Reserved
R
TXFLR
Transmit FIFO Level. Contains the number of valid data
entries in the transmit FIFO. Size is constrained by the
TXFLR value
0x0
Table 159: I2C_RXFLR_REG (0x50001378)
Bit
Mode Symbol
Description
Reset
0x0
15:6
5:0
-
-
Reserved
R
RXFLR
Receive FIFO Level. Contains the number of valid data
entries in the receive FIFO. Size is constrained by the
RXFLR value
0x0
Table 160: I2C_SDA_HOLD_REG (0x5000137C)
Bit
Mode Symbol
R/W IC_SDA_HOLD
Description
Reset
15:0
SDA Hold time
0x1
Table 161: I2C_TX_ABRT_SOURCE_REG (0x50001380)
Bit
Mode Symbol
Description
Reset
15
R
R
ABRT_SLVRD_INTX
1: When the processor side responds to a slave mode
request for data to be transmitted to a remote master and
user writes a 1 in CMD (bit 8) of 2IC_DATA_CMD register
0x0
14
ABRT_SLV_ARBLOS 1: Slave lost the bus while transmitting data to a remote
0x0
T
master.
I2C_TX_ABRT_SOURCE[12] is set at the same time. Note:
Even though the slave never "owns" the bus, something
could go wrong on the bus. This is a fail safe check. For
instance, during a data transmission at the low-to-high tran-
sition of SCL, if what is on the data bus is not what is sup-
posed to be transmitted, then the controller no longer own
the bus.
13
12
R
R
ABRT_SLVFLUSH_T
XFIFO
1: Slave has received a read command and some data
exists in the TX FIFO so the slave issues a TX_ABRT inter-
rupt to flush old data in TX FIFO.
0x0
0x0
ARB_LOST
1: Master has lost arbitration, or if
I2C_TX_ABRT_SOURCE[14] is also set, then the slave
transmitter has lost arbitration. Note: I2C can be both master
and slave at the same time.
11
10
R
R
ABRT_MASTER_DIS 1: User tries to initiate a Master operation with the Master
mode disabled.
0x0
0x0
ABRT_10B_RD_NO
RSTRT
1: The restart is disabled (IC_RESTART_EN bit
(I2C_CON[5]) = 0) and the master sends a read command in
10-bit addressing mode.
