Table 5 DC Characteristics
Symbol
Parameter
Conditions (1) (2)
LIMITS
Max
Unit
Min
LOGIC INPUTS AND OUTPUTS
VIH
VIL
HI level input voltage
LO level input voltage
2.0
V
0.8
V
VIhst
Input hysteresis voltage,
SCLK input
(3)
50
mV
VOH
HI level output voltage
Iout = -20uA
VCC – 0.1
V
Iout = -4.5mA,
3.2
3.0
V
V
-55°C to +85°C
-55°C to +125°C
Iout = 20uA
VOL
LO level output voltage
0.1
Iout = 4.5mA,
-55°C to +85°C
-55°C to +125°C
Vin = VCC or GND
0.33
0.4
V
IIN
Input leakage
Logic inputs except SDIN:
-55°C to +85°C
-55°C to +125°C
-1
-2
-2
1
2
750
uA
uA
SDIN:
IOZ
Max 3-state leakage current, Output in Hi Impedance state.
DOUT
Vout = VCC or GND
-5
-10
5
10
-55°C to +85°C
-55°C to +125°C
Cin
Logic input pin Capacitance (3)
10
15
pF
pF
Cout
DOUT pin capacitance,
output in HI-Z state
(3)
DISCRETE INPUTS
VIH
VIL
VIhst
IIH
HI level input voltage
LO level input voltage
Input hysteresis voltage
HI level input current
VDD = 18V
VDD = 5.0V
VDD = 18V
VDD = 5.0V
VDD = 18V
16.9
4.16
V
V
V
16.0
3.7
0.59
0.18
VDD = 5.0V
DINn = 18V
5
10
-55°C to +85°C
-55°C to +125°C
DINn = 40V
uA
20
40
-55°C to +85°C
-55°C to +125°C
DINn = 0V
IIL
LO level input current
VDD = 18V
VDD = 5.0V
SUPPLY VOLTAGES
-1.0
-0.25
-1.6
-0.5
mA
uA
ICC
Max quiescent logic supply Logic inputs = VCC or GND
current DIN[8:1] = Open
-55°C to +85°C
-55°C to +125°C
200
400
©2018 Device Engineering, Inc.
Page 7 of 11
DS-MW-01066-01 Rev J
04/18/2018
