CY8C9520A, CY8C9540A
CY8C9560A
DC Electrical Characteristics
DC Chip-Level Specifications
Table 20 lists guaranteed maximum and minimum specifications for the voltage and temperature ranges: 4.75V to 5.25V and -40°C
≤ TA ≤ 85°C, or 3.0V to 3.6V and -40°C ≤ TA ≤ 85°C, respectively. Typical parameters apply to 5V and 3.3V at 25°C and are for design
guidance only.
Table 20. CY8C9520A DC Chip-Level Specifications
Symbol
Vdd
Description
Supply voltage
Min
3.00
Typ
Max
5.25
Units
Notes
–
V
IDD
Supply current Vdd 5V
Supply current Vdd 3.3V
–
–
3.8
2.3
5
3
mA
mA
Conditions are 5.0V, TA = 25 oC, IOH = 0.
Conditions are 3.3V, TA = 25 oC, IOH = 0.
IDD3
Table 21. CY8C9540A DC Chip-Level Specifications
Symbol
Vdd
Description
Supply voltage
Min
3.00
Typ
Max
Units
Notes
–
5.25
9
V
IDD
Supply current Vdd 5V
Supply current Vdd 3.3V
–
–
6
mA
mA
Conditions are 5.0V, TA = 25 oC, IOH = 0.
Conditions are 3.3V, TA = 25 oC, IOH = 0.
IDD3
3.3
6
Table 22. CY8C9560A DC Chip-Level Specifications
Symbol
Vdd
Description
Supply voltage
Min
3.00
Typ
Max
Units
Notes
–
5.25
25
9
V
IDD
Supply current Vdd 5V
Supply current Vdd 3.3V
–
–
15
5
mA
mA
Conditions are 5.0V, TA = 25 oC, IOH = 0.
Conditions are 3.3V, TA = 25 oC, IOH = 0.
IDD3
DC Programming Specifications
The following table lists guaranteed maximum and minimum specifications for the voltage and temperature ranges: 4.75V to 5.25V
and -40°C ≤ TA ≤ 85°C, or 3.0V to 3.6V and -40°C ≤ TA ≤ 85°C, respectively. Typical parameters apply to 5V and 3.3V at 25°C and
are for design guidance only.
Table 23. DC Programming Specifications
Symbol
FlashENPB
FlashENT
FlashDR
Description
Min
Typ
Max
Units
Notes
Flash (EEPROM) endurance (by block) 10,000
–
–
–
–
–
–
–
Erase/write cycles by block.
Erase/write cycles.
Flash endurance (total)a
Flash data retention
1,800,000
10
–
Years
a. A maximum of 36 x 50,000 block endurance cycles is allowed. This may be balanced between operations on 36x1 blocks of 50,000 maximum cycles each, 36x2 blocks of 25,000 maximum cycles
each, or 36x4 blocks of 12,500 maximum cycles each (to limit the total number of cycles to 36x50,000 and that no single block ever sees more than 50,000 cycles).
