CY8C9520A, CY8C9540A
CY8C9560A
To read device configuration the user must:
Read E2 POR Defaults Cmd (04h)
This command reads the POR settings stored in the EEPROM.
To read POR defaults the user must:
■ Write command 06h
■ Read 146 data bytes (see Table 16).
■ Read 1 CRC byte.
■ Write command 04h
■ Read 146 data bytes (see Table 16)
■ Read 1 CRC byte.
Reconfigure Device Cmd (07h)
This command immediately reconfigures the device with actual
POR defaults from EEPROM. It has the same effect on the
registers as a POR.
Write Device Config Cmd (05h)
This command sends a new device configuration to the
CY8C95xx. It is followed by 146 data bytes according to
Table 16. The CRC is calculated as the XOR of the 146 data
bytes (00h-91h). If the CRC check fails or an incomplete block is
sent, then the slave responds with a NAK and the device does
not use the data. This gives the user ‘flat-address-space’ access
to all device settings.
To set the current device configuration the user must:
■ Write command 05h
■ Write 146 data bytes with new values of registers
■ Write 1 CRC byte calculated as XOR of previous 146 data
bytes.
If the CRC check passes, then the device uses the new settings
immediately.
Content of the data block is described in Table 16.
Read Device Config Cmd (06h)
This command reads the current device configuration. It gives
the user ‘flat-address-space’ access to all device settings.
Document Number: 38-12036 Rev. *B
Page 14 of 24
