PSoC® 3: CY8C32 Family
Data Sheet
11.1.4 XRES
Table 11-16. XRES DC Specifications
Parameter
VIH
VIL
Description
Input voltage high threshold
Input voltage low threshold
Conditions
Min
0.7 × VDDIO
–
Typ
–
–
Max
–
0.3 ×
VDDIO
Units
V
V
Rpullup
CIN
Pull-up resistor
Input capacitance[33]
3.5
–
5.6
3
8.5
–
kΩ
pF
VH
Input voltage hysteresis
(Schmitt-Trigger)[33]
–
100
–
mV
Idiode
Current through protection diode to
–
–
100
µA
VDDIO and VSSIO
Table 11-17. XRES AC Specifications
Parameter
Description
Reset pulse width
Conditions
Min
Typ
Max
Units
TRESET
1
–
–
µs
Document Number: 001-56955 Rev. *J
Page 78 of 119
